Wifi 5.8 Ghz Yagi Antenna / 5700-5900MZH Outdoor Yagi Antenna Wifi 5ghz

Product Categories

SHENZHEN ZD TECH CO., LTD

Contact Now

Brand Name : ZD

Model Number : ZD-OYA-5759-17.5NF

Certification : RoHS

Place of Origin : china

MOQ : Negotiable

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000pcs per month

Packaging Details : Standard Packing

Freq. Range : 5725-5850 MHz

Bandwidth : 125 MHz

Gain : 17.5dBi

VSWR : ≤1.5

Weight : 1.2kg

Antenna Length : 520 mm

Contact Now

5.8G Yagi antenna 5700-5900MZH yagi antenna outdoor antenna

Applications:

wifi system

Features:

* Small Size, Low Profile

* Lightweight ABS Radome

* outdoor Used

Specifications
Model	ZD-OYA-5759-17.5NF
Freq. Range	5725-5850 MHz
Bandwidth	125 MHz
Gain	17.5dBi
Horizontal Beamwidth	19±3°
Vertical Beamwidth	19±3°
Number Of Element	34
F/B Ratio	> 20dB
VSWR	≤1.5
Impedance	50 ohm
Polarization	Vertical
Max. Power	100 W
Connector	N Female
Lightning Protection	DC Ground
Antenna Length	520 mm
Weight	1.2kg
Rated Wind Velocity	Rated Wind Velocity
Diameter of installation pole	Φ30~ 50mm
Working Temperature	-40’C~+60’C

Wifi 5.8 Ghz Yagi Antenna / 5700-5900MZH Outdoor Yagi Antenna Wifi 5ghz
